Description

ADDA AD1224UB-F53 is a high-performance 24V DC axial cooling fan designed for demanding industrial and electronic cooling applications. Featuring a robust aluminum frame, ball-bearing construction, high airflow output of approximately 120 CFM, and long operational life, it provides reliable thermal management for servers, power supplies, telecom equipment, control panels, and automation systems. Brand: ADDA Corporation Model: AD1224UB-F53 Product Type: DC Axial Cooling Fan Voltage: 24 VDC Frequency: Not Applicable (DC Fan) Current: 0.40 A (Typical) Power Consumption: 9.6 W Fan Size: 120 × 120 × 38 mm Blade Material: PBT Thermoplastic (UL94V-0) Frame Material: Aluminum Alloy Bearing Type: Ball Bearing Number of Wires: 2 / 3 Wire Versions Available Rotational Speed: 3200 RPM Air Flow: 120 CFM (Approx.) Static Pressure: 8.5 mmAq Noise Level: 48 dBA Mounting Type: Flange Mount Operating Temperature: -10°C to +70°C Life Expectancy: Up to 70,000 Hours
