Description

Model No.: TXWF-85 Fan Type: DC Brushless Axial Fan Rated Voltage: 18V DC Operating Voltage: 12V – 18V (variant based) Current: ~0.20 – 0.21 A Power: ~3.6 W Speed: ~2000 – 2500 RPM Air Flow: ~45 – 50 CFM Noise Level: ~25 – 30 dBA Bearing Type: Ball / Sleeve / Hydraulic Blade Type: 7 Blades Material: PBT Plastic (UL94V-0) Color: Black Fan Size: ~85 mm Dimension: ~119 × 85 × 18.5 mm Mounting Hole Distance: ~107 mm Connector: 2 Pin, 2 Wire Life Span: ~30,000 – 50,000 Hours Operating Temperature: -10°C to +70°C
