Description

Brand: Nidec Model Number: V12E24BMM9-51 Product Type: DC Cooling Fan Fan Type: Axial Flow Fan Rated Voltage: 24 V DC Current: 0.30 A Power Consumption: 7.2 W Air Flow: 100 CFM Rotational Speed: 4500 RPM Bearing Type: Ball Bearing Noise Level: 45-50 dBA Number of Wires: 3 Wires Blade Material: Plastic Motor Type: Brushless (BLDC) Frame Material: Plastic Fan Size: 120 x 120 x 38 mm Insulation Resistance: 100 MΩ Minimum Dielectric Strength: 500 VAC for 1 Minute Operating Temperature: -10°C to +70°C Mounting Type: Panel Mount Life Expectancy: Up to 70,000 Hours Application: Industrial Equipment, Telecom Systems, Power Supplies, Control Panels, Servers, Automation Machinery. Features: High Airflow Performance, Long Service Life, Energy Efficient Operation, Low Maintenance, Continuous Duty Performance, Reliable Cooling, Industrial Grade Construction, Stable Operation.
