Description

Product Type: SIMATIC TP700 Comfort HMI Panel Display Size: 7 Inch TFT Color Touchscreen Resolution: 800 × 480 Pixels Supply Voltage: 24 V DC Power Consumption: Approx. 12 W Current Rating: Approx. 0.5 A Display Colors: 16 Million Colors Touch Type: Analog Resistive Touchscreen Communication Interface: PROFINET, PROFIBUS DP, MPI, Ethernet, USB Memory: 12 MB Configuration Memory Front Protection: IP65 Rear Protection: IP20 Operating Temperature: 0°C to +50°C Dimensions (W × H × D): 214 × 158 × 63 mm Weight: Approx. 1.4 kg Application: Industrial Automation, PLC Control, Machine Monitoring Warranty: 12 Months
