Description

Model : K2E250-AH34-06 Brand : ebm-papst Product Type : AC Centrifugal Cooling Fan Fan Size : 250 mm Air Flow : 770 m³/hr Motor Power : 95 W (50 Hz), 135 W (60 Hz) Speed : 2550 RPM (50 Hz), 2660 RPM (60 Hz) Phase : Single Phase Voltage : 230 VAC Frequency : 50/60 Hz Current : 0.43 A (50 Hz), 0.60 A (60 Hz) Motor Type : M2E068-DF Fan Type : Backward Curved Centrifugal Fan Bearing Type : Ball Bearing Blade Material : Plastic Number Of Blades : 5 Blades Protection Class : IP44 Insulation Class : Class B Mounting Type : Panel Mounted Electrical Connection : Terminal Box Capacitor : 2 µF Rotation : Clockwise (Rotor Side) Impeller Diameter : 250 mm (25 cm / 9.84 in) Overall Dimensions : 280 × 280 × 135 mm (28 × 28 × 13.5 cm / 11.02 × 11.02 × 5.31 in) Operating Temperature : -30°C to +55°C
